STP12NM50N N-channel 500V - 0.29 - 11A - TO-220 /FP- D2PAK - DPAK Second generation MDmeshTM Power MOSFET General features Type VDSS (@Tjmax) RDS(on) ID STB12NM50N 550V <0.38 11A STD12NM50N 550V <0.38 11A STF12NM50N 550V <0.38 11A (1) STP12NM50N 550V <0.38 11A 100% avalanche tested Low input capacitance and gate charge Low gate input resistancel 3 1 3 1 DPAK 2 TO-220 3 3 1 DPAK 2 1 TO-220FP Description This series of devices is realized with the second generation of MDmeshTM Technology. This revolutionary MOSFET associates a new vertical structure to the Company's strip layout to yield one of the world's lowest on-resistance and gate charge. It is therefore suitable for the most demanding high efficiency converters Internal schematic diagram Applications Switching application Order codes Part number Marking Package Packaging STB12NM50N B12NM50N DPAK Tape & reel STD12NM50N D12NM50N DPAK Tape & reel STF12NM50N F12NM50N TO-220FP Tube STP12NM50N P12NM50N TO-220 Tube April 20

STP12NM50N N-channel 500V - 0.29 - 11A - TO-220 /FP- D2PAK - DPAK Second generation MDmeshTM Power MOSFET General features Type VDSS (@Tjmax) RDS(on) ID STB12NM50N 550V <0.38 11A STD12NM50N 550V <0.38 11A STF12NM50N 550V <0.38 11A (1) STP12NM50N 550V <0.38 11A 100% avalanche tested Low input capacitance and gate charge Low gate input resistancel 3 1 3 1 DPAK 2 TO-220 3 3 1 DPAK 2 1 TO-220FP Description The STx12NM50N is realized with the second generation of MDmeshTM Technology. This revolutionary MOSFET associates a new vertical structure to the Company's strip layout to yield one of the world's lowest on-resistance and gate charge. It is therefore suitable for the most demanding high efficiency converters Internal schematic diagram Applications Switching application Order codes Sales Type Marking Package Packaging STB12NM50N B12NM50N DPAK TAPE & REEL STD12NM50N D12NM50N DPAK TAPE & REEL STF12NM50N F12NM50N TO-220FP TUBE STP12NM50N P12NM50N TO-220 TUBE March 2006 Rev 5

STP12NM50N N-channel 500V - 0.29 - 11A - TO-220 /FP- D2PAK - DPAK Second generation MDmeshTM Power MOSFET General features Type VDSS (@Tjmax) RDS(on) ID STB12NM50N 550V <0.38 11A STD12NM50N 550V <0.38 11A STF12NM50N 550V <0.38 11A (1) STP12NM50N 550V <0.38 11A 100% avalanche tested Low input capacitance and gate charge Low gate input resistancel 3 1 3 1 DPAK 2 TO-220 3 3 1 DPAK 2 1 TO-220FP Description This series of devices is realized with the second generation of MDmeshTM technology. This revolutionary Power MOSFET associates a new vertical structure to the company's strip layout to yield one of the world's lowest on-resistance and gate charge. It is therefore suitable for the most demanding high efficiency converters Internal schematic diagram Applications Switching application Order codes Part number Marking Package Packaging STB12NM50N B12NM50N DPAK Tape & reel STD12NM50N D12NM50N DPAK Tape & reel STF12NM50N F12NM50N TO-220FP Tube STP12NM50N P12NM50N TO-220 Tube No

STP12NM50N - STF12NM50N STB12NM50N - STD12NM50N N-CHANNEL 500V - 0.33 - 11 A TO-220/FP/D2PAK/DPAK SECOND GENERATION MDmeshTM MOSFET TARGET SPECIFICATION Table 1: General Features Figure 1: Package TYPE VDSS RDS(on) ID STB12NM50N STD12NM50N STF12NM50N STP12NM50N 500 V 500 V 500 V 500 V < 0.38 < 0.38 < 0.38 < 0.38 11 A 11 A 11 A (*) 11 A WORLD'S LOWEST ON RESISTANCE TYPICAL R DS(on) = 0.33 100% AVALANCHE TESTED LOW INPUT CAPACITANCE AND GATE CHARGE LOW GATE INPUT RESISTANCE 3 1 3 1 TO-220 2 D2PAK 3 3 1 1 DESCRIPTION The STP12NM50N is realized with the second generation of MDmesh Technology. This revolutionary MOSFET associates a new vertical structure to the Company's strip layout to yield the world's lowest on-resistance and gate charge. It is therefore suitable for the most demanding high efficiency converters DPAK 2 TO-220FP Figure 2: Internal Schematic Diagram APPLICATIONS The MDmeshTM II family is very suitable for increasing power density of high voltage converters a

STP12NM50N N-channel 500 V, 0.29 , 11 A MDmeshTM II Power MOSFET TO-220 - DPAK - D2PAK - I2PAK - TO-220FP Features Type VDSS (@Tjmax) RDS(on) max ID 3 STB12NM50N 550 V 0.38 11 A STD12NM50N 550 V 0.38 11 A STI12NM50N 550 V 0.38 11 A STF12NM50N 550 V 0.38 11 A (1) STP12NM50N 550 V 0.38 11 A 1 3 12 2 IPAK TO-220 3 1 DPAK 3 100% avalanche tested Low input capacitance and gate charge Low gate input resistance Application 3 1 1 DPAK Figure 1. 2 TO-220FP Internal schematic diagram Switching applications Description This series of devices is realized with the second generation of MDmeshTM technology. This revolutionary Power MOSFET associates a new vertical structure to the company's strip layout to yield one of the world's lowest on-resistance and gate charge. It is therefore suitable for the most demanding high efficiency converters. Table 1. Device summary Order codes Marking Package Packaging STB12NM50N B12NM50N DPAK Tape and reel STD12NM50N D12NM50N DPAK Tape and reel STI12NM50N I12NM50

STP12NM50N N-channel 500 V, 0.29 , 11 A MDmeshTM II Power MOSFET TO-220 - DPAK - D2PAK - I2PAK - TO-220FP Features Type VDSS (@Tjmax) RDS(on) max ID STB12NM50N 550 V 0.38 11 A STD12NM50N 550 V 0.38 11 A STI12NM50N 550 V 0.38 11 A STF12NM50N 550 V 0.38 11 A (1) STP12NM50N 550 V 0.38 11 A 3 12 2 IPAK TO-220 3 DPAK r P e 1 100% avalanche tested Low input capacitance and gate charge Low gate input resistance Application t e l o DPAK ) (s Switching applications u d o 1 3 ) s ( ct 3 1 s b O Figure 1. 3 1 2 TO-220FP Internal schematic diagram t c u Description d o r This series of devices is realized with the second generation of MDmeshTM technology. This revolutionary Power MOSFET associates a new vertical structure to the company's strip layout to yield one of the world's lowest on-resistance and gate charge. It is therefore suitable for the most demanding high efficiency converters. P e t e l o s b O Table 1. Device summary Order codes Marking Package Packaging STB12NM50N B12NM50N DPAK T

STP12NM50N - STF12NM50N STB12NM50N - STD12NM50N N-CHANNEL 500V - 0.33 - 11 A TO-220/FP/D2PAK/DPAK SECOND GENERATION MDmeshTM MOSFET Table 1: General Features Figure 1: Package TYPE VDSS (@Tjmax) RDS(on) ID STB12NM50N STD12NM50N STF12NM50N STP12NM50N 550 V 550 V 550 V 550 V < 0.38 < 0.38 < 0.38 < 0.38 11 A 11 A 11 A (*) 11 A 100% AVALANCHE TESTED LOW INPUT CAPACITANCE AND GATE CHARGE LOW GATE INPUT RESISTANCE DESCRIPTION The STx12NM50N is realized with the second generation of MDmesh Technology. This revolutionary MOSFET associates a new vertical structure to the Company's strip layout to yield one of the world's lowest on-resistance and gate charge. It is therefore suitable for the most demanding high efficiency converters 3 1 3 1 TO-220 2 D2PAK 3 3 1 1 DPAK 2 TO-220FP Figure 2: Internal Schematic Diagram APPLICATIONS The MDmeshTM II family is very suitable for increasing power density of high voltage converters allowing system miniaturization and higher efficiencies. Table 2: Order

STP12NM50N - STF12NM50N STB12NM50N - STD12NM50N N-CHANNEL 500V - 0.33 - 11 A TO-220/FP/D2PAK/DPAK SECOND GENERATION MDmeshTM MOSFET TARGET SPECIFICATION Table 1: General Features Figure 1: Package TYPE VDSS RDS(on) ID STB12NM50N STD12NM50N STF12NM50N STP12NM50N 500 V 500 V 500 V 500 V < 0.38 < 0.38 < 0.38 < 0.38 11 A 11 A 11 A (*) 11 A WORLD'S LOWEST ON RESISTANCE TYPICAL R DS(on) = 0.33 100% AVALANCHE TESTED LOW INPUT CAPACITANCE AND GATE CHARGE LOW GATE INPUT RESISTANCE 3 1 3 1 TO-220 2 D2PAK 3 3 1 1 DESCRIPTION The STP12NM50N is realized with the second generation of MDmesh Technology. This revolutionary MOSFET associates a new vertical structure to the Company's strip layout to yield the world's lowest on-resistance and gate charge. It is therefore suitable for the most demanding high efficiency converters DPAK 2 TO-220FP Figure 2: Internal Schematic Diagram APPLICATIONS The MDmeshTM II family is very suitable for increasing power density of high voltage converters a
