SPC582B-DIS SPC582B-DIS Discovery board Data brief Description The discovery board SPC582-DIS helps you to discover SPC58B Line Power Architecture(R) Microcontrollers with full access to CPUs, I/O signals and peripherals at budget price. Dedicated connectors allow plugging Arduino shields (Arduino-compatible). Free ready-to-run application firmware examples are available inside SPC5Studio to support quick evaluation and development. Features SPC582B 32-bit z2 core @80Mhz CPU, 32-bit Power Architecture(R) Technology CPU, 1MB Code Flash in eQFP64 package. On-board USB-JTAG PLS debugger and dedicated optional connector to plug a standalone JTAG debugger. USB Virtual Communication port. Two types of extension resources: - Arduino Uno Revision 3 connectivity - Extension headers for all device pins and for quick connection to prototyping expansion boards, additional modules and evaluation probing. Flexible board power supply: - USB port (mini B - 5V) - external sources (DC): 7/12 V, 5V or

d debugger (up to 128Kbyte free) Can, Lin Connectivity on board (included transceivers) Standard connector (type A) Focused for Motor control Application Dual 4x37 connector Can, Lin Connectivity on board (included transceivers) 38 SPC58 Discoveries World SPC582B-DIScovery with SPC582B60E1 order code: SPC582B-DIS SPC58EC-Discovery+ with SPC58EC80E order code: SPC58EC-DISP SPC58NG-Discovery+ with SPC58NE84E7 order code: SPC58NG-DISP * * * * * * * * * Embedded debugger (up to 128Kbyte free) I/O accessible on connectors Standard connector (type A) SPC584B-Discovery with SPC584B70E1 order code: SPC584B-DIS * * * Embedded debugger (up to 128Kbyte free) I/O accessible on connectors Standard connector (type A) Embedded debugger (up to 128Kbyte free) Can, Lin Connectivity on board (+ transceivers) Ethernet 10-100Mbps on board SPC584B-Discovery+ with SPC584B70E5 order code: SPC584B-DISP * * * Embedded debugger (up to 128Kbyte free) Can, Lin Connectivity on board (+ transceivers) Ethernet 10-1

ry Kit for the SPC56 P Line with SPC560P50L5. SPC560P50L5 SPC57 K line SPC574K-DIS [Available soon] Discovery Kit for the SPC57 K Line with SPC574K72E5. SPC574K72E5 SPC57 S line SPC570S-DISP Discovery Kit for the SPC57 S Line with SPC570S50L3. SPC570S50L3 SPC582B-DIS [Available soon] Discovery Kit for the SPC58 B Line with SPC582B60E1. SPC582B60E1 SPC584B-DIS [Available soon] Discovery Kit for the SPC58 B Line with SPC584B70E1. SPC584B70E1 SPC58 B line 13 SPC5 Premium evaluation boards With SPC5 Premium boards developers can quickly evaluate all the functionalities of SPC5 automotive MCUs. Adapter boards are available for each specific device line and package granting full access to all of the CPU's signals and motherboard peripherals for advanced development. Supported by both SPC5 Studio and 3rd party software tools Modular approach saves development time and costs 14 Premium evaluation board features * Modular evaluation system for the SPC5 microcontroller's families * RS232/SCI physical inter
