to 105C -40 to 105C -40 to 105C -40 to 105C -40 to 105C -40 to 105C 4.4.7 K20 family features (120MHz Performance) MK20FX512VMD12(R) MK20FN1M0VMD12(R) CPU Frequency 120 MHz 120 MHz 120 MHz 120 MHz Pin Count 144 144 144 144 LQFP LQFP MAPBGA MAPBGA 1MB 1MB MK20FX512VLQ12(R) MK20FN1M0VLQ12(R) Table 9. K20 120MHz Performance Table MC Partnumber General Package Memories and Memory Interfaces Total Flash Memory 1MB 1MB Table continues on the next page... K20 Family Product Brief, Rev. 11, 08/2012 Freescale Semiconductor, Inc. 31 Features MK20FX512VLQ12(R) MK20FN1M0VLQ12(R) MK20FX512VMD12(R) MK20FN1M0VMD12(R) Table 9. K20 120MHz Performance Table (continued) Flash 512KB 1MB 512KB 1MB FlexNVM 512KB - 512KB - EEPROM/FlexRAM 16KB - 16KB - SRAM 128KB 128KB 128KB 128KB Serial Programming Interface YES YES YES YES External Bus Interface (FlexBus), Addr/Data/CS 32/32/6 32/32/6 32/32/6 32/32/6 MC Partnumber Non-Muxed External Bus Interface (Flexbus), Addr/ Data/CS 30/16/6, 30/8/6 30/16/6, 30/8/6 3

to 105C -40 to 105C -40 to 105C -40 to 105C -40 to 105C -40 to 105C 4.4.7 K20 family features (120MHz Performance) MK20FX512VMD12(R) MK20FN1M0VMD12(R) CPU Frequency 120 MHz 120 MHz 120 MHz 120 MHz Pin Count 144 144 144 144 LQFP LQFP MAPBGA MAPBGA 1MB 1MB MK20FX512VLQ12(R) MK20FN1M0VLQ12(R) Table 9. K20 120MHz Performance Table MC Partnumber General Package Memories and Memory Interfaces Total Flash Memory 1MB 1MB Table continues on the next page... K20 Family Product Brief, Rev. 11, 08/2012 Freescale Semiconductor, Inc. 31 Features MK20FX512VLQ12(R) MK20FN1M0VLQ12(R) MK20FX512VMD12(R) MK20FN1M0VMD12(R) Table 9. K20 120MHz Performance Table (continued) Flash 512KB 1MB 512KB 1MB FlexNVM 512KB - 512KB - EEPROM/FlexRAM 16KB - 16KB - SRAM 128KB 128KB 128KB 128KB Serial Programming Interface YES YES YES YES External Bus Interface (FlexBus), Addr/Data/CS 32/32/6 32/32/6 32/32/6 32/32/6 MC Partnumber Non-Muxed External Bus Interface (Flexbus), Addr/ Data/CS 30/16/6, 30/8/6 30/16/6, 30/8/6 3

MK20FX512VLQ12, MK20FN1M0VLQ12, MK20FX512VMD12, MK20FN1M0VMD12 Key features * Operating Characteristics - Voltage range: 1.71 to 3.6 V - Flash write voltage range: 1.71 to 3.6 V - Temperature range (ambient): -40 to 105C * Performance - Up to 120 MHz Arm(R) Cortex(R)-M4 core with DSP instructions delivering 1.25 Dhrystone MIPS per MHz * Memories and memory interfaces - Up to 1024 KB program flash memory on nonFlexMemory devices - Up to 512 KB program flash memory on FlexMemory devices - Up to 512 KB FlexNVM on FlexMemory devices - 16 KB FlexRAM on FlexMemory devices - Up to 128 KB RAM - Serial programming interface (EzPort) - FlexBus external bus interface - NAND flash controller interface * Clocks - 3 to 32 MHz crystal oscillator - 32 kHz crystal oscillator - Multi-purpose clock generator * System peripherals - Multiple low-power modes to provide power optimization based on application requirements - Memory protection unit with multi-master protection - 32-channel DMA controller, supporting up t

MK20FX512VLQ12, MK20FN1M0VLQ12, MK20FX512VMD12, MK20FN1M0VMD12 Features * Operating Characteristics - Voltage range: 1.71 to 3.6 V - Flash write voltage range: 1.71 to 3.6 V - Temperature range (ambient): -40 to 105C * Performance - Up to 120 MHz ARM Cortex-M4 core with DSP instructions delivering 1.25 Dhrystone MIPS per MHz * Memories and memory interfaces - Up to 1024 KB program flash memory on nonFlexMemory devices - Up to 512 KB program flash memory on FlexMemory devices - Up to 512 KB FlexNVM on FlexMemory devices - 16 KB FlexRAM on FlexMemory devices - Up to 128 KB RAM - Serial programming interface (EzPort) - FlexBus external bus interface - NAND flash controller interface * Clocks - 3 to 32 MHz crystal oscillator - 32 kHz crystal oscillator - Multi-purpose clock generator * System peripherals - Multiple low-power modes to provide power optimization based on application requirements - Memory protection unit with multi-master protection - 32-channel DMA controller, supporting up to 128 requ

MK20FX512VLQ12, MK20FN1M0VLQ12, MK20FX512VMD12, MK20FN1M0VMD12 Key features * Operating Characteristics - Voltage range: 1.71 to 3.6 V - Flash write voltage range: 1.71 to 3.6 V - Temperature range (ambient): -40 to 105C * Performance - Up to 120 MHz ARM Cortex-M4 core with DSP instructions delivering 1.25 Dhrystone MIPS per MHz * Memories and memory interfaces - Up to 1024 KB program flash memory on nonFlexMemory devices - Up to 512 KB program flash memory on FlexMemory devices - Up to 512 KB FlexNVM on FlexMemory devices - 16 KB FlexRAM on FlexMemory devices - Up to 128 KB RAM - Serial programming interface (EzPort) - FlexBus external bus interface - NAND flash controller interface * Clocks - 3 to 32 MHz crystal oscillator - 32 kHz crystal oscillator - Multi-purpose clock generator * System peripherals - Multiple low-power modes to provide power optimization based on application requirements - Memory protection unit with multi-master protection - 32-channel DMA controller, supporting up to 128

MK20FX512VLQ12, MK20FN1M0VLQ12, MK20FX512VMD12, MK20FN1M0VMD12 Key features * Operating Characteristics - Voltage range: 1.71 to 3.6 V - Flash write voltage range: 1.71 to 3.6 V - Temperature range (ambient): -40 to 105C * Performance - Up to 120 MHz ARM(R) Cortex(R)-M4 core with DSP instructions delivering 1.25 Dhrystone MIPS per MHz * Memories and memory interfaces - Up to 1024 KB program flash memory on nonFlexMemory devices - Up to 512 KB program flash memory on FlexMemory devices - Up to 512 KB FlexNVM on FlexMemory devices - 16 KB FlexRAM on FlexMemory devices - Up to 128 KB RAM - Serial programming interface (EzPort) - FlexBus external bus interface - NAND flash controller interface * Clocks - 3 to 32 MHz crystal oscillator - 32 kHz crystal oscillator - Multi-purpose clock generator * System peripherals - Multiple low-power modes to provide power optimization based on application requirements - Memory protection unit with multi-master protection - 32-channel DMA controller, supporting up t

Signal Integration (cont.) [1] [1,3] [1] [1] [1] [1] [1] [1] [1] [1,2] [1,2] [1,2] [1,2] MK20DN512VMD10 MK20DN512ZCAB10R MK20DX128VLQ10 MK20DX128VMD10 MK20DX256VLK10 MK20DX256VLQ10 MK20DX256VMC10 MK20DX256VMD10 MK20DX256VLL10 MK20FN1M0VLQ12 MK20FN1M0VMD12 MK20FX512VLQ12 MK20FX512VMD12 100 MHz 100 MHz 100 MHz 100 MHz 100 MHz 100 MHz 100 MHz 100 MHz 100 MHz 120 MHz 120 MHz 120 MHz 120 MHz 144 120 144 144 80 144 121 144 100 144 144 144 144 MAPBGA WLCSP LQFP MAPBGA LQFP LQFP MAPBGA MAPBGA LQFP LQFP MAPBGA LQFP MAPBGA 512 KB 512 KB 256 KB 256 KB 512 KB 512 KB 512 KB 512 KB 512 KB 1MB 1MB 1MB 1MB 512 KB 512 KB 128 KB 128 KB 256 KB 256 KB 256 KB 256 KB 256 KB 1MB 1MB 512 KB 512 KB - - 128 KB 128 KB 256 KB 256 KB 256 KB 256 KB 256 KB - - 512 KB 512 KB - - 4 KB 4 KB 4 KB 4 KB 4 KB 4 KB 4 KB - - 16 KB 16 KB 128 KB 128 KB 32 KB 32 KB 64 KB 64 KB 64 KB 64 KB 64 KB 128 KB 128 KB 128 KB 128 KB 6 6 6 6 4 6 6 6 5 6 6 6 6 1 1 1 1 1 1 1 1 1 2 2 2 2 1 1 1 1 1 1 1 1 1 0 0 0 0 8 4 8 8 4 8 8 8 4 8 8 8 8 16 16 16 16 16

Signal Integration (cont.) [1] [1,3] [1] [1] [1] [1] [1] [1] [1] [1,2] [1,2] [1,2] [1,2] MK20DN512VMD10 MK20DN512ZCAB10R MK20DX128VLQ10 MK20DX128VMD10 MK20DX256VLK10 MK20DX256VLQ10 MK20DX256VMC10 MK20DX256VMD10 MK20DX256VLL10 MK20FN1M0VLQ12 MK20FN1M0VMD12 MK20FX512VLQ12 MK20FX512VMD12 100 MHz 100 MHz 100 MHz 100 MHz 100 MHz 100 MHz 100 MHz 100 MHz 100 MHz 120 MHz 120 MHz 120 MHz 120 MHz 144 120 144 144 80 144 121 144 100 144 144 144 144 MAPBGA WLCSP LQFP MAPBGA LQFP LQFP MAPBGA MAPBGA LQFP LQFP MAPBGA LQFP MAPBGA 512 KB 512 KB 256 KB 256 KB 512 KB 512 KB 512 KB 512 KB 512 KB 1MB 1MB 1MB 1MB 512 KB 512 KB 128 KB 128 KB 256 KB 256 KB 256 KB 256 KB 256 KB 1MB 1MB 512 KB 512 KB - - 128 KB 128 KB 256 KB 256 KB 256 KB 256 KB 256 KB - - 512 KB 512 KB - - 4 KB 4 KB 4 KB 4 KB 4 KB 4 KB 4 KB - - 16 KB 16 KB 128 KB 128 KB 32 KB 32 KB 64 KB 64 KB 64 KB 64 KB 64 KB 128 KB 128 KB 128 KB 128 KB 6 6 6 6 4 6 6 6 5 6 6 6 6 1 1 1 1 1 1 1 1 1 2 2 2 2 1 1 1 1 1 1 1 1 1 0 0 0 0 8 4 8 8 4 8 8 8 4 8 8 8 8 16 16 16 16 16

144 LQFP 100 Y 1024 1024 - - 128 6 2 0 8 Y 2 Y Y 3 6/4/2 2 2 2 2x8ch 2x2ch 4ch 58ch 4 2 4 5/2/2/5 Y 16 T10 [1,2] MK20FN1M0VMD12 120 Y Y 32ch 144 MAPBGA 100 Y 1024 1024 - - 128 6 2 0 8 Y 2 Y Y 3 6/4/2 2 2 2 2x8ch 2x2ch 4ch 58ch 4 2 4 5/2/2/5 Y 16 T10 [1,2] MK20FX512VLQ12 120 Y Y 32ch 144 LQFP 100 Y 1024 512 512 16 128 6 2 0 8 Y 2 Y Y 3 6/4/2 2 2 2 2x8ch 2x2ch 4ch 58ch 4 2 4 5/2/2/5 Y 16 T10 [1,2] MK20FX512VMD12 120 Y Y 32ch 144 MAPBGA 100 Y 1024 512 512 16 128 6 2 0 8 Y 2 Y Y 3 6/4/2 2 2 2 2x8ch 2x2ch 4ch 58ch 4 2 4 5/2/2/5 Y 16 T10 [1,2] MK20FX512VMD12 120 16 KB 128 KB 6 2 16 6/4/2 2 2 2 2x 8ch 2x 2ch 2 1 1 4ch 58ch 4 2 4 5/2/2/5 Y Y 32ch Y MAPBGA 1MB 512 KB 512 KB 0 8 Common Features Temp Range: -40 C to 105 C Voltage Range: 1.71-3.6 V Flash Write Voltage: 1.71 V Main OSC: 32-40 KHz/8-32 MHz Debug: JTAG, cJTAG, SWD RTC (32 KHz OSC, Vbat) Trace: TPIU, FPB, DWT, ITM 12 NXP--Selector guide 2018 Footnotes 2x FTM External Clk, 1x Low Power Timer, 1x Programmable Delay Block PIT (32 bit): 1x4ch Hardwa
