wide range of voltages. Operation from split power supplies is also possible and the low power supply current drain is independent of the magnitude of the power supply voltage. P TSSOP-14 (Thin shrink small outline package) Order codes Part number LM124N LM124D/DT LM224N LM224D/DT Temperature range -55C, +125C -40C, +105C LM224PT LM324N LM324D/DT LM324PT October 2006 0C, +70C Package Packing DIP SO DIP SO TSSOP (Thin shrink outline package) DIP SO TSSOP (Thin shrink outline package) Tube Tube or tape & reel Tube Tube or tape & reel Rev 5 Tape & reel Tube Tube or tape & reel Tape & reel 1/19 www.st.com 19 Contents LM124-LM224-LM324 Contents 1 Pin & schematic diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 2 Absolute maximum ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 3 Electrical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 4 Typical single-supply applications . . . . . . . . . .

wide range of voltages. Operation from split power supplies is also possible and the low power supply current drain is independent of the magnitude of the power supply voltage. P TSSOP-14 (Thin shrink small outline package) Order codes Part number LM124N LM124D/DT LM224N LM224D/DT Temperature range -55C, +125C -40C, +105C LM224PT LM324N LM324D/DT LM324PT October 2006 0C, +70C Package Packing DIP SO DIP SO TSSOP (Thin shrink outline package) DIP SO TSSOP (Thin shrink outline package) Tube Tube or tape & reel Tube Tube or tape & reel Rev 5 Tape & reel Tube Tube or tape & reel Tape & reel 1/19 www.st.com 19 Absolute maximum ratings 2 LM124-LM224-LM324 Absolute maximum ratings Table 1. Absolute maximum ratings Symbol VCC Vi Parameter LM124 Supply voltage Input voltage Vid Differential input voltage Ptot Power dissipation N suffix D suffix (1) Input current (3) Toper Operating free-air temperature range Tstg Storage temperature range LM324 Unit 16 or 32 V 32 V 32 V 500 500 400 Output short-circuit du

wide range of voltages. Operation from split power supplies is also possible and the low power supply current drain is independent of the magnitude of the power supply voltage. P TSSOP-14 (Thin Shrink Small Outline Package) Order Codes Part Number LM124N LM124D/DT LM224N LM224D/DT Temperature Range -55C, +125C -40C, +105C LM224PT LM324N LM324D/DT LM324PT January 2005 0C, +70C Package Packaging DIP SO DIP SO TSSOP (Thin Shrink Outline Package) DIP SO TSSOP (Thin Shrink Outline Package) Tube Tube or Tape & Reel Tube Tube or Tape & Reel Revision 2 Tape & Reel Tube Tube or Tape & Reel Tape & Reel 1/15 LM124-LM224-LM324 Pin & Schematic Diagram 1 Pin & Schematic Diagram Figure 1: Pin connections (top view) 14 Output 4 Output 1 1 Inverting Input 1 2 - - 13 Inverting Input 4 Non-inverting Input 1 3 + + 12 Non-inverting Input 4 11 VCC - VCC + 4 Non-inverting Input 2 5 + + 10 Non-inverting Input 3 Inverting Input 2 6 - - 9 Inverting Input 3 Output 2 7 Figure 2: Schematic diagram (1/4 LM124) 2/15 8 Output

L1 16/19 Inches 0.60 0.0256 0.75 0.018 1.00 0 0.024 0.030 0.039 8 0.10 Doc ID 2156 Rev 7 0 8 0.004 LM124, LM224, LM324 Ordering information 6 Ordering information Table 6. Order codes Part number Temperature range Package Packing Marking DIP14 Tube LM124N LM124D/DT SO-14 Tube or tape & reel 124 LM224N DIP14 Tube LM224N SO-14 Tube or tape & reel 224 LM224PT TSSOP14 Tape & reel 224 LM224QT QFN16 3x3 Tape & reel K425 DIP14 Tube LM324N SO-14 Tube or tape & reel 324 LM324PT TSSOP14 Tape & reel 324 LM324QT QFN16 3x3 Tape & reel K427 LM124N -55C, +125C LM224D/DT -40C, +105C LM324N LM324D/DT 0C, +70C Doc ID 2156 Rev 7 17/19 Revision history 7 LM124, LM224, LM324 Revision history 0 Table 7. Document revision history Date Revision 01-Oct.-2003 1 First release. 02-Jan-2005 2 Modifications on AMR Table 1 on page 3 (explanation of Vid and Vi limits). 01-Jun-2005 3 ESD protection inserted in Table 1 on page 3. 02-Jan-2006 4 Tj and Rthjc parameters added in Table 1. on page 3. 04-Oct-2006 5 Editorial update. Ta

wide range of voltages. Operation from split power supplies is also possible and the low power supply current drain is independent of the magnitude of the power supply voltage. P TSSOP-14 (Thin shrink small outline package) Order codes Part number LM124N LM124D/DT LM224N LM224D/DT Temperature range -55C, +125C -40C, +105C LM224PT LM324N LM324D/DT LM324PT October 2006 0C, +70C Package Packing DIP SO DIP SO TSSOP (Thin shrink outline package) DIP SO TSSOP (Thin shrink outline package) Tube Tube or tape & reel Tube Tube or tape & reel Rev 5 Tape & reel Tube Tube or tape & reel Tape & reel 1/19 www.st.com 19 Absolute maximum ratings 2 LM124-LM224-LM324 Absolute maximum ratings Table 1. Absolute maximum ratings Symbol VCC Vi Parameter LM124 Supply voltage Input voltage Vid Differential input voltage Ptot Power dissipation N suffix D suffix (1) Input current (3) Toper Operating free-air temperature range Tstg Storage temperature range LM324 Unit 16 or 32 V 32 V 32 V 500 500 400 Output short-circuit du

wide range of voltages. Operation from split power supplies is also possible and the low power supply current drain is independent of the magnitude of the power supply voltage. P TSSOP-14 (Thin shrink small outline package) Order codes Part number LM124N LM124D/DT LM224N LM224D/DT Temperature range -55C, +125C -40C, +105C LM224PT LM324N LM324D/DT LM324PT October 2006 0C, +70C Package Packing DIP SO DIP SO TSSOP (Thin shrink outline package) DIP SO TSSOP (Thin shrink outline package) Tube Tube or tape & reel Tube Tube or tape & reel Rev 5 Tape & reel Tube Tube or tape & reel Tape & reel 1/19 www.st.com 19 Contents LM124-LM224-LM324 Contents 1 Pin & schematic diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 2 Absolute maximum ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 3 Electrical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 4 Typical single-supply applications . . . . . . . . . .

wide range of voltages. Operation from split power supplies is also possible and the low power supply current drain is independent of the magnitude of the power supply voltage. P TSSOP-14 (Thin shrink small outline package) Order codes Part number LM124N LM124D/DT LM224N LM224D/DT Temperature range -55C, +125C -40C, +105C LM224PT LM324N LM324D/DT LM324PT 0C, +70C Package Packing DIP SO DIP SO TSSOP (Thin shrink outline package) DIP SO TSSOP (Thin shrink outline package) Tube Tube or tape & reel Tube Tube or tape & reel Tape & reel Tube Tube or tape & reel Tape & reel 1/19 19 Absolute maximum ratings 2 LM124-LM224-LM324 Absolute maximum ratings Table 1. Absolute maximum ratings Symbol VCC Vi Parameter LM124 Supply voltage Input voltage Vid Differential input voltage Ptot Power dissipation N suffix D suffix (1) Input current (3) Toper Operating free-air temperature range Tstg Storage temperature range LM324 Unit 16 or 32 V 32 V 32 V 500 500 400 Output short-circuit duration (2) Iin LM224 500 400 m

L1 16/19 Inches 0.60 0.0256 0.75 0.018 1.00 0 0.024 0.030 0.039 8 0.10 Doc ID 2156 Rev 7 0 8 0.004 LM124, LM224, LM324 Ordering information 6 Ordering information Table 6. Order codes Part number Temperature range Package Packing Marking DIP14 Tube LM124N LM124D/DT SO-14 Tube or tape & reel 124 LM224N DIP14 Tube LM224N SO-14 Tube or tape & reel 224 LM224PT TSSOP14 Tape & reel 224 LM224QT QFN16 3x3 Tape & reel K425 DIP14 Tube LM324N SO-14 Tube or tape & reel 324 LM324PT TSSOP14 Tape & reel 324 LM324QT QFN16 3x3 Tape & reel K427 LM124N -55C, +125C LM224D/DT -40C, +105C LM324N LM324D/DT 0C, +70C Doc ID 2156 Rev 7 17/19 Revision history 7 LM124, LM224, LM324 Revision history 0 Table 7. Document revision history Date Revision 01-Oct.-2003 1 First release. 02-Jan-2005 2 Modifications on AMR Table 1 on page 3 (explanation of Vid and Vi limits). 01-Jun-2005 3 ESD protection inserted in Table 1 on page 3. 02-Jan-2006 4 Tj and Rthjc parameters added in Table 1. on page 3. 04-Oct-2006 5 Editorial update. Ta

wide range of voltages. Operation from split power supplies is also possible and the low power supply current drain is independent of the magnitude of the power supply voltage. P TSSOP-14 (Thin Shrink Small Outline Package) Order Codes Part Number LM124N LM124D/DT LM224N LM224D/DT Temperature Range -55C, +125C -40C, +105C LM224PT LM324N LM324D/DT LM324PT June 2005 0C, +70C Package Packaging DIP SO DIP SO TSSOP (Thin Shrink Outline Package) DIP SO TSSOP (Thin Shrink Outline Package) Tube Tube or Tape & Reel Tube Tube or Tape & Reel Tape & Reel Tube Tube or Tape & Reel Tape & Reel Rev 3 1/16 www.st.com 16 Absolute Maximum Ratings 1 LM124-LM224-LM324 Absolute Maximum Ratings Table 1. 15Key parameters and their absolute maximum ratings Symbol VCC Parameter LM124 Supply voltage LM224 LM324 Unit 16 or 32 V Vi Input Voltage -0.3 to Vcc + 0.3 V Vid Differential Input Voltage (1) -0.3 to Vcc + 0.3 V Ptot Power Dissipation N Suffix D Suffix 500 500 400 Output Short-circuit Duration (2) Iin Input Current (

L1 16/19 Inches 0.60 0.0256 0.75 0.018 1.00 0 0.024 0.030 0.039 8 0.10 Doc ID 2156 Rev 7 0 8 0.004 LM124, LM224, LM324 Ordering information 6 Ordering information Table 6. Order codes Part number Temperature range Package Packing Marking DIP14 Tube LM124N LM124D/DT SO-14 Tube or tape & reel 124 LM224N DIP14 Tube LM224N SO-14 Tube or tape & reel 224 LM224PT TSSOP14 Tape & reel 224 LM224QT QFN16 3x3 Tape & reel K425 DIP14 Tube LM324N SO-14 Tube or tape & reel 324 LM324PT TSSOP14 Tape & reel 324 LM324QT QFN16 3x3 Tape & reel K427 LM124N -55C, +125C LM224D/DT -40C, +105C LM324N LM324D/DT 0C, +70C Doc ID 2156 Rev 7 17/19 Revision history 7 LM124, LM224, LM324 Revision history 0 Table 7. Document revision history Date Revision 01-Oct.-2003 1 First release. 02-Jan-2005 2 Modifications on AMR Table 1 on page 3 (explanation of Vid and Vi limits). 01-Jun-2005 3 ESD protection inserted in Table 1 on page 3. 02-Jan-2006 4 Tj and Rthjc parameters added in Table 1. on page 3. 04-Oct-2006 5 Editorial update. Ta

wide range of voltages. Operation from split power supplies is also possible and the low power supply current drain is independent of the magnitude of the power supply voltage. P TSSOP-14 (Thin shrink small outline package) Order codes Part number LM124N LM124D/DT LM224N LM224D/DT Temperature range -55C, +125C -40C, +105C LM224PT LM324N LM324D/DT LM324PT 0C, +70C Package Packing DIP SO DIP SO TSSOP (Thin shrink outline package) DIP SO TSSOP (Thin shrink outline package) Tube Tube or tape & reel Tube Tube or tape & reel Tape & reel Tube Tube or tape & reel Tape & reel 1/19 19 Absolute maximum ratings 2 LM124-LM224-LM324 Absolute maximum ratings Table 1. Absolute maximum ratings Symbol VCC Vi Parameter LM124 Supply voltage Input voltage Vid Differential input voltage Ptot Power dissipation N suffix D suffix (1) Input current (3) Toper Operating free-air temperature range Tstg Storage temperature range LM324 Unit 16 or 32 V 32 V 32 V 500 500 400 Output short-circuit duration (2) Iin LM224 500 400 m

1.00 0.65 0.45 L1 16/19 Inches 0.60 0.0256 0.75 0.018 1.00 0 0.024 0.030 0.039 8 0.10 Doc ID 2156 Rev 6 0 8 0.004 LM124, LM224, LM324 Ordering information 7 Ordering information Table 6. Order codes Part number Temperature range Package Packing DIP14 Tube LM124D/DT SO-14 Tube or tape & reel LM224N DIP14 Tube SO-14 Tube or tape & reel LM224PT TSSOP14 (Thin shrink outline package) Tape & reel LM324N DIP14 Tube SO-14 Tube or tape & reel TSSOP14 (Thin shrink outline package) Tape & reel LM124N -55C, +125C LM224D/DT LM324D/DT LM324PT -40C, +105C 0C, +70C Doc ID 2156 Rev 6 17/19 Revision history 8 LM124, LM224, LM324 Revision history 0 Table 7. 18/19 Document revision history Date Revision Changes 01-Oct.-2003 1 First release. 02-Jan-2005 2 Modifications on AMR Table 1 on page 3 (explanation of Vid and Vi limits). 01-Jun-2005 3 ESD protection inserted in Table 1 on page 3. 02-Jan-2006 4 Tj and Rthjc parameters added in Table 1. on page 3. 04-Oct-2006 5 Editorial update. Table 3 moved to Section 5: Macr

wide range of voltages. Operation from split power supplies is also possible and the low power supply current drain is independent of the magnitude of the power supply voltage. P TSSOP-14 (Thin shrink small outline package) Order codes Part number LM124N LM124D/DT LM224N LM224D/DT Temperature range -55C, +125C -40C, +105C LM224PT LM324N LM324D/DT LM324PT October 2006 0C, +70C Package Packing DIP SO DIP SO TSSOP (Thin shrink outline package) DIP SO TSSOP (Thin shrink outline package) Tube Tube or tape & reel Tube Tube or tape & reel Rev 5 Tape & reel Tube Tube or tape & reel Tape & reel 1/19 www.st.com 19 Absolute maximum ratings 2 LM124-LM224-LM324 Absolute maximum ratings Table 1. Absolute maximum ratings Symbol VCC Vi Parameter LM124 Supply voltage Input voltage Vid Differential input voltage Ptot Power dissipation N suffix D suffix (1) Input current (3) Toper Operating free-air temperature range Tstg Storage temperature range LM324 Unit 16 or 32 V 32 V 32 V 500 500 400 Output short-circuit du

wide range of voltages. Operation from split power supplies is also possible and the low power supply current drain is independent of the magnitude of the power supply voltage. P TSSOP-14 (Thin Shrink Small Outline Package) Order Codes Part Number LM124N LM124D/DT LM224N LM224D/DT Temperature Range -55C, +125C -40C, +105C LM224PT LM324N LM324D/DT LM324PT January 2006 0C, +70C Package Packing DIP SO DIP SO TSSOP (Thin Shrink Outline Package) DIP SO TSSOP (Thin Shrink Outline Package) Tube Tube or Tape & Reel Tube Tube or Tape & Reel Tape & Reel Tube Tube or Tape & Reel Tape & Reel Rev 4 1/16 www.st.com 16 Absolute Maximum Ratings 1 LM124-LM224-LM324 Absolute Maximum Ratings Table 1. Key parameters and their absolute maximum ratings Symbol VCC Parameter LM124 Supply voltage LM224 LM324 Unit 16 or 32 V Vi Input Voltage -0.3 to V CC + 0.3 V Vid Differential Input Voltage (1) -0.3 to V CC + 0.3 V Ptot Power Dissipation N Suffix D Suffix 500 500 400 Output Short-circuit Duration (2) Iin Input Current
